Transistor BC549 NPN, 0.1A TO-92

Transistor BC549 NPN, 0.1A TO-92

Transistors

Reference: TRBC549

Part.No: BC549

€0.50

Last items in stock

Immediate Dispatch

The BC549 is a low-noise NPN Bipolar Junction Transistor (BJT) in a TO-92 package. Engineered for audio amplification, microphone preamps and sensitive signal processing where minimal noise is critical.

Add to cart

Subscribe To When In Stock

You have successfully subscribed to this product

Description
Product Details

BC549 Low-Noise NPN Transistor – Audio-Grade Amplification

The BC549 is a premium NPN transistor optimized for audio and low-noise applications. With exceptional gain stability and a carefully controlled noise figure, it is the preferred choice for microphone preamps, phono stages, guitar effects, and any circuit where signal purity is non-negotiable.

Functions & Applications

Low Noise Figure: Exceptional purity for microphone preamps, phono stages and studio equipment.
High DC Current Gain (hFE): Strong amplification of weak audio signals without requiring additional stages.
Tight Gain Selection: Matched units ensure consistent performance across matched-pair applications.
Standard TO-92 Package: Through-hole design, compatible with breadboards and PCBs.

Technical Specifications

Parameter	Value / Specification
Transistor Type	BJT (Bipolar Junction Transistor)
Polarity / Channel	NPN
Package / Case	TO-92
Collector-Emitter Voltage (Vceo)	45V
Max Collector Current (Ic)	100mA
Power Dissipation (Pd)	500mW
Noise Figure	Low (optimized for audio)
Mounting Type	Through-Hole (THT)

Frequently Asked Questions

Q: Can I use BC549 as a direct replacement for BC547?
A: Yes. The BC549 is an audio-grade upgrade to the BC547 with lower noise. It will work perfectly as a drop-in replacement and will often improve signal purity in sensitive circuits.

Q: Is the BC549 suitable for microphone preamps?
A: Absolutely. The BC549 is specifically engineered for microphone preamplifiers and other low-noise audio stages. Its low noise figure makes it ideal for weak microphone signals.

Notes

Audio-grade transistor: select matched pairs for stereo applications. Not a NOS/vintage part—standard production.

Note: Price refers to one (1) piece. The component is shipped in bulk without individual packaging.

Transistor Type: BJT (Bipolar Junction Transistor)
Transistor Polarity / Channel: NPN
Transistor Case Style: TO-92
