Part.No: AX-3005DS
€105.00
Upon Request
Delivered within 2-3 days

The Axiomet AX-3005DS is a modern 150W Switching Mode Power Supply (SMPS) designed for efficiency and portability. It offers fully adjustable output from 0-30V and 0-5A in a lightweight, compact chassis. Featuring clear backlit LCD screens and separate Coarse/Fine adjustment knobs, it is the perfect tool for service technicians, schools, and electronics enthusiasts.



Compact Power & Switching Precision

The AXIOMET AX-3005DS is a single-channel laboratory power supply utilizing Switching Mode (SMPS) technology. Unlike bulky linear transformers, this unit delivers a robust 150W (30V/5A) output while remaining exceptionally lightweight and compact, saving valuable bench space.

It is equipped with dual backlit LCDs for simultaneous monitoring of voltage and current readings. Precise control is achieved through four rotary potentiometers, allowing for separate Coarse and Fine tuning of both voltage and current parameters.

Key Features

  • Switching Technology: High efficiency operation, reduced heat generation, and lightweight design for easy portability.
  • Dual LCD Display: Clear 3-digit readouts for Voltage and Current (V & A) with backlight.
  • Precision Control: Dedicated Coarse and Fine knobs enable quick yet accurate setting of output values.
  • CV & CC Modes: Automatic crossover between Constant Voltage and Constant Current modes, suitable for current-limiting applications.
  • Safety: Built-in Overload Protection (OPP) to safeguard connected devices.

Technical Specifications

Output Voltage 0 - 30V DC (Adjustable)
Output Current 0 - 5A DC (Adjustable)
Max Power 150W
Display 2x LCD 3-digit (Backlit)
Voltage Regulation ≤ 1% + 10mV
Ripple & Noise ≤ 200mVp-p
Input Voltage 230V AC, 50Hz
Dimensions 85 x 160 x 205 mm
Weight ~ 1.5 kg

Applications

The AX-3005DS is highly versatile and recommended for:

  • Electronics service centers (Laptops, Mobile phones).
  • DIY enthusiasts needing a reliable and lightweight power source.
  • Educational institutions and robotics labs.
  • Battery charging (thanks to the CC regulation capabilities).

📦 What's in the Box

  • 1x Axiomet AX-3005DS Power Supply
  • 1x Power Cord
  • 1x Output Test Leads
  • 1x User Manual
